Smart
Slide
Series
Sliding doors designed to combine performance with value. Manufactured in very large dimensions with an easy to operate locking mechanism: the comfortable closing sash slides into the frame with a soft motion while creating a compression seal to prevent sound, water and air from infiltrating.

Features
• Multi-Chamber profile design delivers superior thermal performance compared to traditional aluminum door systems
• European hardware system with multi-point locking complete with innovative 4-side compression delivering unmatched water and air tightness
• Sleek frame depth at 5 3/8 suitable for both new construction
and retrofit applications
Key Performance Data
0.16 (IP) 0.90 (SI)
U-Value Best Thermal NFRC
720 Pa
8.36 psf
Water Penetration Resistance
0.300 L/s*m² (A3)
0.06 cfm/ft²
Air Infiltration
* All data shown are for triple paned windows and doors. For more information about performance data for specific configurations and add-ons, please speak to our design representative
Resources
Bi-Folding Door Installation Manual
1800 & 4700 Series Windows and Doors Installation Manual
Smart Slide Doors Installation Manual
Protective Film Handling Instructions
ThermoPlus PHC Passive House Report optimized
ThermoPlus PHC Passive House Certificate
Series 4700 ThermoPlus PHC Performance Chart
NFRC Thermal Performance Summary
Folding Door Configurations (Inswing Fold)
Folding Door Configurations (Outswing Fold)
Legacy Door Design Spec- Assembled View
Legacy Door Design Spec- Detailed View
4700 Hybrid Outswing Door Sills
4700 Hybrid Inswing Door Sills
GANA Proper Procedures For Cleaning Glass
CAD Files
Configuration Options
One Direction Slide

Two Direction Slide
