Swing Door

Previous
Next

EuroLine swing doors combine the most innovative technologies with unique design and functionality. Capable of meeting the most rigorous Passive House energy standards and available in both inswing and outswing options, providing supreme air and water tightness. Custom solutions in both size and configuration, whether single, double, or French style, combined with virtually any finish creates endless design possibility while dramatically improving the energy performance of buildings.

RAU-FIPRO ThermoPlus Swing Doors

Design + Engineering Meets Technology

  • Hybrid uPVC and fiberglass material (RAU-FIPRO) delivers SIX CHAMBER PROFILE with superior strength for oversized openings.
  • Outstanding air and water with resistance triple gasket system
  • Multipoint locking hardware, easy to operate providing tight seal and security
  • Capable of surpassing your local building requirements, including progressive Step Code and delivering Passive House performance when desired
  • This system offers various products: Tilt and Turn Windows and Doors, Tilt and Glide Doors, and French Doors – all tailored to your needs
  • Sill options: Standard, Low and Barrier Free increasing the versatility without limiting performance
  • Single Doors, Double Doors with connected side lights and/or transoms; endless possibilities

Key Performance Data

0.13 (IP)
0.70 (SI)

U-Value
Best Thermal NFRC

720 Pa
15 psf

Water Penetration Resistance

0.004 L/s*m² (A3)
0.001 cfm/ft²

Air Infiltration

* All data shown are for double paned windows and doors. For more information about performance data for specific configurations and add-ons, please speak to our design representative

Powerdur Swing Door

Design + Engineering Meets Technology

  • Elimination of thermal bridging, as a result of glass fiber reinforced Powerdur technology replacing any steel reinforcements
  • Outstanding air, water, and noise resistance through a triple gasket system
  • 33% larger openings without steel reinforcement due to its six- chamber profile with superior strength Powerdur
  • Ease of operation, tight seal, andburglary protection provided byadvanced multi-point lockinghardware

Key Performance Data

0.21 (IP)
1.19 (SI)

U-Value
Best Thermal NFRC

730 Pa
15 psf

Water Penetration Resistance

0.005 L/s*m² (A3)
0.001 cfm/ft²

Air Infiltration

* All data shown are for double paned windows and doors. For more information about performance data for specific configurations and add-ons, please speak to our design representative

Design + Engineering Meets Technology

  • Open sashes 180 degrees
  • Standard, low, and barrier-free sill options available
  • Available with tilt function
  • Elimination of thermal bridging thanks to glass fiber-reinforced powerdur technology replacing the need for steel reinforcements
  • Outstanding air, water, and noise resistance with triple gasket system
  • 33% larger openings without steel reinforcement thanks to its six chamber profile with superior strength powerdur
  • Ease of operation, tight seal, and burglary protection provided by advanced multi-point locking hardware

For Curated Details that Customize Your Project

Obscure Glass

Perfect For The Following Applications

Passive House
PHIUS certification
Large openings
Extreme climates
Oceanfront properties
Aggressive air, water, and energy requirements
Passive House and PHIUS builds
Single-family homes
High-rises and commercial buildings

For Curated Details that Customize Your Project

Obscure Glass

Perfect For The Following Applications

Large openings
Aggressive air, water, and energy requirements
Oceanfront properties
Extreme climates
Single-family homes
High-rise residential or commercial buildings
Passive House and PHIUS builds

Key Performance Data

0.21 (IP)
1.19 (SI)

 U-Value Best Thermal NFRC

730 Pa
15 psf

Water Penetration Resistance

0.005 L/s*m² (A3)
0.001 cfm/ft²

Air Tightness

* All data shown are for double paned windows and doors. For more information about performance data for specific configurations and add-ons, please speak to our design representative

Configuration Options

Single
Door

Added
Transom

French Style
Double Door

Single Door with
Long Fixed

Tilt & Turn
Door

Double Door with Sidelites

Sidelites & Transom

Single Door,
Multiple Fixed

Technology That Helps Improve Your Standard of Living

Powerdur Reinforcements

With conventional door solutions, the componentry that loses heat most are the steel reinforcements, sending precious thermal energy into the atmosphere. Powerdur is EuroLine’s solution to this challenge. Powerdur is an innovative fully recyclable glass fiber reinforced synthetic material. It is used inside the profiles as reinforcement to provide the required level of stability, eliminating the need for steel reinforcement. Additional reinforcements can be used to enlarge door sizes further

Key Property Benefits:

  • Up to 33% bigger openings without the need for steel reinforcement
  • Stabilizes the profile from within
  • Renders steel reinforcements unnecessary
  • Up to 20% lighter and yet even more stable than conventional
    windows, saving fuel during transport and protecting the environment
  • 100% recyclable
  • The granulated PVC can be separated accurately from the Powerdur
    material and then fed back into the production cycle several times
    without compromising the quality of the material at all. As a result,
    Powerdur guarantees a closed-loop material cycle contributing to an
    excellent eco-balance
With Powerdur
With Steel
Combination of Both
  • System multifunctionality: with interchangeable profiles,
    our clients can choose between:
    – a conventional solution with steel
    – a solution without steel
    – a possible combination of both.
    The mutual compatibility of profiles allows individual profile
    geometries to be freely combined, providing the potential for
    various stylistic configurations of windows.
  • The addition of optional foam for improved thermal performance
  • White or dark inside profile base colours available
  • The choice of a custom finish from EuroLine’s 125+ colour
    and texture library, including wood grains

The optional addition of foam to the inside of some chambers creates remarkable thermal insulation values. In this process the central interior chambers of the window frame and sash are filled completely with foam. This technology enables foam-filled windows to reach record-breaking insulation figures of up to 0.60 W/m2K, both generating a financial value for our clients and contributing to the saving of global finite resources such as oil and gas.

EuroLine Swing Door system is one of the few systems that feature the “classic center seal”. This special extruded middle rebate is where the third, internal seal strongly adheres, ensuring greater tightness of the entire construction and improving its thermal, acoustic, and burglar resistance properties. In comparison to regular windows and doors, the center seal also makes it more difficult for burglars to force open the sash by blocking access to the hardware.

Environmental Impact

  • Swing Doors are composed of a resource-efficient system that saves energy, conserves resources, and reduces CO2 emissions.
  • Swing Door system is 15% lower CO2 footprint compared to a conventional, steel-reinforced door.
  • 30-38% of Swing Door profile is made from recycled uPVC.
  • A closed-loop material cycle and an excellent eco balance are guaranteed with 100% recyclable powerdur. The granulated PVC can be separated accurately from the powerdur material and fed back into the production cycle several times- without compromising the quality of the material at all.
  • Reduced CO2 emission from transportation. The profile depth is a determining factor for efficient logistics. Increasing profile depth by 15-20mm reduces the load volume of a conventional rack by up to 20%!
